Piling Services

Bored Piles

A high load capacity pile with a lot of design flexibility which can be installed with minimal noise and vibration, suitable for a wide range of ground conditions. Suitable for high-rise construction, infrastructure tunnel shafts, bridges to retaining walls and tight urban sites.

• Capabilities up to 90 metres deep, 5 metres diameter
• Permanent or temporary casing
• Drilled under suspension fluids as required

CFA Piles

A high production rate technique with low noise, low vibration, suitable for urban areas and poor ground conditions.

• Capabilities up to 27 metres deep, 1200 millimetres diameter

Displacement Piles (FDP)

Minimal soil removal high-capacity piling technique – where soil is displaced laterally during drilling rather than extracted. Especially useful in contaminated, loose and granular soils.

• Capabilities up to 600 millimetres diameter, 28 metres deep

Soil Mixing

A cost-effective, environmentally friendly and high-performance solution to stabilise ground conditions, improve bearing capacity and minimise risks. Suitable where in-situ ground conditions are suitable for mixing applications.

• Capabilities up to 1.4 metres diameter to 28 metres deep

Driven Piles and Sheet Piles

Diaphragm Walls

Deep reinforced concrete walls constructed in-situ, providing excavation support, groundwater control and structural stability. Our micro diaphragm wall solution is especially suited to cost-effective single-level basements and underground car parks.

• Wall depth: 6 metres to 60 metres
• Widths: 0.3 metres to 1.5 metres
• Length: Continuous (individual panels up to 11.4 metres)

Anchors/Soil Nails and Grouting Solutions

Providing various types of anchors and soil nails for slope stabilisation, retaining walls and excavations. Our grouting solutions improve soil strength, fill voids, and reduce permeability, enhancing foundation stability and performance.

Stone Columns and Ground Improvement

Installation of stone column solutions in weak soils to improve load bearing capacity, reduce settlement and increase drainage. Vibro installation ensures efficient liquefaction mitigation and stabilisation for embankments and foundations.

Pile Testing

Comprehensive pile testing services including:

• Static & Dynamic load testing
• Pile Integrity testing (PIT)
• Thermal integrity profiling (TIP)
• Cross sonic logging tube installation and testing (CSL)

Capping Beams and Pile Caps

Design and installation of capping beams and pile caps to suit a wide range of applications, effectively integrating our piles into our clients' structure.

Shotcrete

Offering shotcrete solutions for durable and efficient structural reinforcement, slope stabilisations and tunnel linings.

Bulk and Detailed Excavation

Providing bulk excavation services for large-scale site preparation, tunnelling, basements, and infrastructure. Our detailed excavation services ensure precise shaping and preparation of footings, trenches, and utilities, meeting exact project specifications with accuracy and care.
